| Model No. | Step Angle° | Current /Winding A |
Resistance /Phase Ω |
Inductance /Phase mH |
Weight Kg |
Length mm |
| Single Shaft | ||||||
| 57CA4(X)-3.25-ENG-E | 1.8 | 2 | 1.63 | 3.5±20% | 0.511 | 44.5 |
| 57NA4(X)-3.25-ENG-E | 1.8 | 2 | 1.63 | 3.5±20% | 0.511 | 44.5 |
| 57EA4(X)-3.25-ENG-E | 1.8 | 2 | 1.63 | 3.5±20% | 0.511 | 44.5 |
| 57CCA4(X)-2.33-ENG-E | 1.8 | 3.32 | 0.98 | 2.6±20% | 0.958 | 64.5 |
| 57NCA4(X)-2.33-ENG-E | 1.8 | 3.32 | 0.98 | 2.6±20% | 0.958 | 64.5 |
| 57ECA4(X)-2.33-ENG-E | 1.8 | 3.32 | 0.98 | 2.6±20% | 0.958 | 64.5 |
